SKZ111A-1 Portable Textile Moisture Meter
Description
1. High-frequency (10MHz) principle
2. 316L SS + PTFE probe, corrosion/wear resistant
3. A/B measurement switch
4. Range 0-80%
5. Segmented acc.: ±0.2%/±0.5%/±1%
6. Resolution 0.1%
7. 600mm long probe
8. Powered by single 9V battery
9. Dimensions 160×60×27mm
10. Net weight 250g
11. Fast measurement
1. 【Optimized for Yarn, 10MHz High-Freq】High-frequency induction technology optimized specifically for yarn moisture detection.
2. 【316L+PTFE Composite Probe】Corrosion and wear resistant for frequent yarn contact – long-lasting durability.
3. 【A/B Dual Measurement Modes】Mode A for cotton yarn, Mode B for polyester and synthetics – one-key switching for accurate matching.
4. 【0-80% Wide Range】From dry yarn to high-moisture yarn – covers all moisture conditions.
5. 【3-Stage Segmented Accuracy】±0.2% (0-10%), ±0.5% (10-40%), ±1% (40-80%) – precision optimized for each range.
6. 【0.1% High Resolution】Captures subtle moisture fluctuations in yarn for precise quality data.
7. 【600mm Long Probe】Reaches inside yarn packages or stacks – avoids surface measurement errors.
8. 【Lightweight 250g】Compact and portable – ideal for mobile inspection at production lines and warehouses.
9. 【9V Battery Powered】Easy replacement without external adapter.
10. 【Fast Measurement】Single test completed in seconds – greatly improves patrol inspection efficiency.
11. 【Designed for Yarn Samples】Specifically optimized for moisture detection of yarn samples.
12. 【Compact 160×60×27mm】Small and portable – one-hand operation.
Specifications
| Display | LCD display |
| Measuring range | 0 ~ 40% |
| Resolution | 0.1% |
| Accuracy | 0%-10%: ±0.2% |
| 10%-40%: ±0.5% | |
| Probe | 50mm |
| Power | 9V battery*1 |
| Dimension | 160mm × 60mm × 27mm |
| Net weight/gross weight | 250g/500g |
| Package size | 260 X 220 X 100 mm |
